EVO 2.4 FIXED RIB -A – short wheel base van-DIY flat pack

EVO  2.4 RIB key features :

Modified for the  Fixed Rib  112cm x 186cm seat bed.

• Side unit with 9 doors & 2 drawers
• 3 X Sliding tambour door
• Over bed locker for low roof and elevating roof vans
• Front bed panel with door and rear bed panel
• 2 drawers one for cutlery and the other extra deep 150mm high
• Concealed self close hinges with flush fitting doors
• Table with folding aluminium leg and  stainless steel sliding rail system
• All connecting blocks, hinges, grey , black or silver edging, push catches and screws
• The front cupboard door unclips to fit a Webasto Cruise 49 ( optimised for this fridge ), Waeco CR50  or CR40 fridge if you wish to install one later.
• Knock on edging for all exposed edges, the edges are pre slot cut for you to apply
• Designed to be easy to construct with easy  mount hinges, slots for aligning the panels and pre drilled hole for the connector blocks
• The worktop cut for a SMEV 9222 sink hob ( righthand sink )
• Available in a range of own light weight ply finishes
• Worktop and Table can be a different finish to the unit.
• Edging: Silver or Dark Grey or black
• Works with Scopema RIB seat 1120mm wide sliding version, BEBB seat, Smart beds Evolution and various rock n roll beds 44” wide or less. EVO 2.4  maximum bed length is 1940mm measured from the back doors.
• Works with both low roof and elevating roof conversions.
• The tambour door next to the bed front gives access under the unit, behind the front bed board there is another access point with no door. The bed board will cover this if using a fixed rib bed.

Does not include:

• Led light shelf
• control panel
• Twin light recess
