Works with various 112cm wide seat beds

• Side unit with 6 doors & 2 drawers
• 2 x sliding tambour doors
• Kitchen splash back is available in a variety of finishes to suit.
• Led light shelf with touch sensitive dimmable switch
• Can be supplied with blinds as an optional extra.
• Control panel with 1x spice rack/ cubby hole. Includes 2x bamboo inserts to mount USBs or digital displays.
• Pre edge banded on most of the exposed edges, speeding up construction time and looks, some edges are pre slot cut for you to apply knock on T-trim
• Over bed locker for low roof and elevating roof vans
• Front bed panel with door and rear bed panel
• 1x 400mm cutlery draw and 1x 450mm draw.
• Aluminium corner profiles
• Concealed self close hinges with flush fitting doors
• Table with folding aluminium leg and stainless steel sliding rail system
• All connecting blocks, hinges, grey, black or silver edging, evomatic catches and screws
• Space for Vitrifrigo C51I, dometic CR50 , Alpicool 50L or similar
• Designed to be easy to construct with easy mount hinges, slots for aligning the panels and pre drilled hole for the connector blocks
• The worktop cut for a SMEV 9722 sink hob ( righthand sink )
• Available in a range of own light weight ply finishes
• Worktop and Table can be a different finish to the unit
• Edging: Silver or Dark Grey or Black
• Works with Scopema RIB seat 1120mm wide sliding version, Smart beds Evolution and various rock n roll beds 44” wide or less.
• Works with both low roof and elevating roof conversions

TO NOTE:

-Bed boards may need a small notch jigsawed out near step, depending on how your bed is mounted

-We have the locker fit for SKYLINE elevating roofs, if you have an alternative brand please contact us

Does not include:

2 door locker over sink this is an option, supplied with Led shelf as standard .

HALO LED, We recommend any COB LED strip lighting (4,5 or 6mm), or standard LED strip lighting.

These are optional extras below

Appliances to fit this unit:

+
