EVO PRO 1300 SWB

£ 1,700.00 inc vat

IMG_6155

Evo 3 VW T5/6 Conversion (SHORT WHEEL BASE VAN)

Carrying up to 6 people securely the long wheel base conversion is an ideal everyday family tourer…cruise down motorways or escape for a holiday. A practical design featuring a generous amount of storage space.

Designed for Webasto Cruise 65 l and Dometic Cramer. Worktop will be cut as standard for the – CE00-Mini-BO-HI27-I-G or DOMETIC HSG 2445 Camping Hob-Sink Combination.

Please note we are no longer providing conversions ourselves but we are selling our designs to any capable converter who wishes to use our designs. This allows you to find a local converter to your selves,

NOTE: LED + DOORS FOR THIS KIT HAS R17mm ALUMINIUM TO ALLOW CLEARANCE FOR THE COOKER LID TO OPEN.

Works with RIB fixed bed 1300 x 1860mm (the longer 1940mm will not work)

IMPORTANT Install the unit before fitting the bed.  – The bed must be installed as far back as possible with the rear cushion slightly crushed into the corner. Always test fit the bed against the units before drilling holes for the bed.

Extras that are are included in the pro version:

  • Satin aluminium corners
  • Ball bearing drawer runners
  • Edge banded drawer fronts and vertical under worktop supports
  • Self locking Evomatic catches.

Kits include all the wood work and fitting to construct the furniture only.

Post leg and table top.

Kit is suitable for trade customers experienced in furniture construction.

Designed  to accommodate 12 liter water bottles under the rib seat.

All other items, appliances, roofs, beds LED light shelf, PMS3 box etc…are not included.



NOTE – Max bed length 1860mm RIB due to the larger 65L fridge. This unit is a tight fit so ensure the bed is installed away from the units as close as possible to the back and side wall of the van.

SaveSave

SaveSave

SaveSave

SaveSave

SaveSave

SaveSave

SaveSave

SaveSave

SaveSave

LEFT or RIGHT hand drive vehicle? *

Unit Finish *

View finishes

View Discontinued Finishes

EVO STOCK RANGE
CPL – Continuous Pressure Laminate
HPL – High Pressure Laminate ( More wear resistant 0.8mm thick )
*Being discontinued once stock is depleted

Worktop & Table Finish *

EDGE TRIM COLOUR *

Roof Type *

Please ignore brackets ( R40 =840 B ) etc…after roof type. ONLY SELECT A FULL WIDTH LOCKER FOR A SLIM KIT (eg. 1300) OR A KIT WITH A LOW BACK (eg. 2.3 5.3)
View Over bed locker types

Bed boards *

These are panels for the front and back of your seat / bed. Please note the Rib bed is available in 2 different frame heights 340 or 330 mm contact your supplier for this info or measure yourself. Ignore brackets ( A ) etc.. after description.
View Bed Board Types

Led light shelf *

Door catch *

Optional extras

Add products to compliment your furniture kit. Please note some kits come with some of the items below

ORDER NOTES

Please add any additional information that you have discussed with us.
